Name: Engineering Graphics &amp; Design
SKU: 72117
Availability: InStock

-20%

Engineering Graphics & Design

4.4 out of 5

967 4.4 out of 5 stars

3537 Views

(0 customer reviews)

DOWNLOAD INFO

Download Catalog

Additional information

ISBN 13	978-93-55381-07-1
ISBN 10	93-55381-07-7
Edition	First
No. of Pages	268
Type of book	Paperback
Weight	420.00 g
Year	2023
Language	Hindi
Publisher	Khanna Publishing House
Save	₹69.6 (20% Off)
Price	Original price was: ₹348.00.Current price is: ₹278.40.
Categories	AICTE Prescribed Textbooks
Condition Type	New
Country Origin	India

In stock

Categories: AICTE Prescribed Textbooks, Book Store, Hindi Books Product ID: 72117

Description

This textbook “Engineering Graphics and Design” is based on the latest outcome based model curriculum of the AICTE. The book covers complete syllabus catering requirements of all major technical universities and institutes and provides insights into traditional engineering graphics as well as treats of the subject using 2D and 3D design software. It offers technical details, current standard, real world examples and clearly explains theory and technique in highly visual and concise format. The topic covered in this book are arranged into 9 chapters comprising self-explanatory diagrams and solved examples.

Salient Features:

1. Introduction of Engineering Drawing

2. Orthographic Projection

3. Projection of Solids

4. Section of Solids and Development of Surfaces

5. Isometric Projection

6. Overview of Computer Graphics

7. CAD Drawing

8. Solid Modelling

9. Team Design Project.

Foreword

Acknowledgement

Preface

Outcome Based Education

Course Outcomes

Abbreviations and Symbols

List of Figures

List of Tables

Guidelines for Teacher

Guidelines for Students

Chapter 1: Introduction of Engineering Drawing.

Chapter 2: Orthographic Projection.

Chapter 3: Projection of Solids.

Chapter 4: Sectional Views of Solids.

Chapter 5: Isometric Projection.

Chapter 6: Overview of Computer Graphics.

Chapter 7: Customization &CAD.

Chapter 8: Annotation Layers and 3D Modelling.

Chapter 9: Projects.

Reference

CO and Po Attainment Table

Index.

Author

Pradeep Jain has 15 years of experience in teaching and industry in CAD/CAM. presently he is working as an associate professor in the Department of Mechanical Engineering, Ajay Kumar Garg Engineering College, Ghaziabad. He is providing training and consultancy in CAD/ CAM field.
