Description
This book is Designed for the students of Engineering and Technology as well as specially for Mechanical Engineering Degree and Diploma students. The teaching of this course faces difficulty in explaining the various concept of machine drawing viz., orthographical projection, sectioning, complicated mechanical assembly drawing etc. Sometimes explanation requires some three dimensional and complicated drawing to be drawn on the black board which is quite impossible due to the time constraint of class.
This book is an outcome of the strong need felt by students offering the course and the teaching need felt by us. The teacher can explain the related concepts, drawing methods and uses of various parts being drawn etc. in each practical class without bothering the black board.
The subject matter has been compressed from the view point of Mechanical Engineering students.
The book also contains Basic Drawing Softwares which describes about the basics of Auto-CAD, CATIA, PROE, ANSYS etc. which is useful for today’s need of Engineering & Technology.
Table of Contents
1. Basic of Machine Drawing
2. Sectional Views
3. Rivets and Riveted Joints
4. Screw Threads and Fasteners
5. Bearings & Shaft Coupling
6. Assembly Drawing
7. Power Transmission Drives
8. Basics Drawing Softwares
Author
O.P. Jakhar
1-
Dr. O.P.
Jakhar: Started his teaching carrier in 2000 as lecturer in
Mechanical Engineering Department as Shri Balaji College of Engineering and Technology
(SBCET, Jaipur. Further he served Stani Memorial College of Engineering and
Technology, Phagi, Jaipur and Ajmer Institute of Technology, Ajmer as Senior
Lecturer. Dr Jakhar joined Maharana Pratap University of Agriculture and
Technology, Udaipur as Assistant Professor in 2005. At Presently he is serving
at Govt. Engineering College, Bikaner as Associate Professor in Mechanical Engineering
department since 2008. His areas of interested are Heat Transfer, Fluid
Mechanics and Machines, Steams Power and Thermal Engineering.
Dr. Jakhar is life member of ISTE and Indian
Geological Congress (IGC) he has guided 10 M.Tech. dissertations and published
more than 40 research papers.
Dr. O.P. Jakhar got commissioned as Lieutenant in NCC in
2005 and presently he is serving as Captain at 7 Raj. BN. NCC, Bikaner.
Amit Mathur
1-Â Â Â Amit
Mathur is presently Assistant Professor & Head in the Department of
Mechanical Engineering at Govt. College of Engineering & Technology,
Bikaner. He has done B.E. (Mechanical Engineering) from Govt. Engineering
College, Ajmer and M.E. (Manufacturing Technology) from NITTTR, Chandigarh. He
has an experience of more than 10 years in the field of Teaching &
Research. He has published more than 06 papers in National Conference Proceedings
& Journals. He is also an Associated member of Institution of Engineers.
India.</p
